Karcher HDS Trailer

Name: Karcher HDS Trailer
Brand: Karcher
SKU: 152498522
Price: 36977.00 GBP
Availability: InStock

HDS Trailer The all-round mobile and self-contained solution for professional use in local authorities, construction and industry. Configurable, highly efficient, reliable and easy to use. The 500 litre water tank and 100 litre fuel tank on board allow for up to 60 minutes of stand-alone use without connecting to electricity or water supplies.

Karcher HDS Trailer HDS 17/20 De Tr1

Self-sufficient and mobile: the HDS 17/20 hot water high-pressure cleaner works without power source at pressures of 200 bar. The highly-efficient HDS Trailer is suitable for the municipal sector, industry and construction.

Thanks to its powerful diesel engine, the HDS 17/20 hot water high-pressure cleaner with 200 bar pressure constantly delivers spotless cleaning results even without electricity. Example applications include construction sites, industry or the municipal sector. Alongside maximum mobility and flexibility, the reliable machine also impresses with its exemplary efficiency. The HDS trailer also scores top marks for ease of servicing and operating comfort. The machine can be configured as required and can therefore be perfectly adapted to individual requests.

Features and benefits

Maximum efficiency

Proven and highly efficient burner technology. Heat recovery through use of waste heat from the engine. Environmentally-friendly operation and low operating costs thanks to Kärcher's eco!efficiency mode.

Easy operation

The machine is easy to operate using a central selector switch. Easy to set up and dismantle thanks to two optional hose reels in the control area. Safe storage thanks to the ample storage options for protective gear, accessories and cleaning agents.

Self-sufficient application

Large 500 l water tank for up to 30-minute cleaning applications with full water performance. With 100 l diesel tank – ideal for long work assignments. Powerful Yanmar diesel engines allow the machine to be used independently of any power source.

High flexibility

Thanks to its configurability, each trailer can be custom-made according to customer requests.
Available as Skid or Cab variant for mobile application as a trailer or as a stationary solution.
A large hood enables service staff to access the internal components more easily.

Easy servicing

Sophisticated service software for rapid fault diagnosis during servicing.
Tried-and-tested high-quality Kärcher components guarantee a long lifetime.
Includes: Water softening system to protect the heating coil against calcification.

Reliability

Numerous safety functions protect the HDS trailer against damage in the case of an error.
Integrated frost protection mode to protect all components in cold exterior temperatures.
Proven and highly efficient burner technology.

Specifications

Technical data

Drive type	Diesel
Motor manufacturer	Yanmar
Engine rating (kW/hp)	19 / 26
Flow rate (l/h)	900 - 1700
Pressure (bar/MPa)	60 - 200 / 6 - 20
Consumption of heating oil in eco!efficiency mode (kg/h)	9,7
Dimensions (L x W x H) (mm)	3646 x 1747 x 1735

Equipment

Spray gun: EASY!Force Advanced
High-pressure hose: 30 m
Spray lance: 1050 mm
Power nozzle
Servo control

Specifications

MPN

1.524-952.2

Country of Origin

DE

Brand

Karcher

Condition

New

Product Code

152498522

Weight

1000kg
